MS0850505F040V2A - E-Switch

MS0850505F040V2A Details

• Manufacturer Part Number:

  MS0850505F040V2A

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.70.00

• Manufacturer:

  E-Switch Inc

• YTEOL:

  8

• Actuator Length:

  0.571 inch

• Actuator Material:

  POLYBUTYLENE TEREPHTHALATE

• Actuator Type:

  ROLLER LEVER

• Body Breadth:

  6.4 mm

• Body Color:

  BLACK

• Body Height:

  9.9 mm

• Body Length or Diameter:

  19.8 mm

• Center Contact Material:

  SILVER

• Center Contact Plating:

  SILVER

• Contact (AC) Max Rating R Load:

  5A@250VAC

• Contact Current(AC)-Max:

  5 A

• Contact Function:

  ON-(ON)

• Contact Resistance:

  0.1 mΩ

• Contact Timing:

  QUICK-MAKE/-BREAK

• Contact Voltage(AC)-Max:

  250 V

• Dielectric Withstand Volts:

  1000VAC V

• Electrical Life:

  50000 Cycle(s)

• End Contact Material:

  SILVER

• End Contact Plating:

  SILVER

• Housing Material:

  POLYBUTYLENE TEREPHTHALATE

• Illumination:

  NON-ILLUMINATED

• Insulation Resistance:

  100000000 Ω

• Insulator Material:

  POLYBUTYLENE TEREPHTHALATE

• Mounting Feature:

  THROUGH HOLE-RIGHT ANGLE

• Operating Force-Max:

  0.59 N

• Operating Position:

  0.587 inch

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -25 °C

• PCB Hole Count:

  3

• Pre-Travel-Max:

  4 mm

• Surface Mount:

  NO

• Switch Action:

  MOMENTARY

• Switch Function:

  SPDT

• Switch Type:

  SNAP ACTING/LIMIT SWITCH

• Terminal Length:

  0.134 inch

• Terminal Material:

  COPPER ALLOY

• Termination Type:

  SOLDER
