MS2310L6 - CIT Relay & Switch

MS2310L6 Details

• Manufacturer Part Number:

  MS2310L6

• Part Life Cycle Code:

  Contact Manufacturer

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.70.00

• Manufacturer:

  CIT Relay & Switch

• Actuator Length:

  0.236 inch

• Actuator Type:

  SLIDE

• Body Breadth:

  4.699 mm

• Body Height:

  6.8072 mm

• Body Length or Diameter:

  12.5984 mm

• Center Contact Material:

  PHOSPHOR BRONZE

• Center Contact Plating:

  SILVER

• Contact Current(DC)-Max:

  0.3 A

• Contact (DC) Max Rating R Load:

  0.3A@50VDC

• Contact Resistance:

  0.05 mΩ

• Contact Voltage(DC)-Max:

  50 V

• Dielectric Withstand Volts:

  1000VRMS V

• Electrical Life:

  10000 Cycle(s)

• End Contact Material:

  PHOSPHOR BRONZE

• End Contact Plating:

  SILVER

• Housing Material:

  STEEL

• Insulation Resistance:

  100000000 Ω

• Insulator Material:

  PHENOLIC

• Mounting Feature:

  THROUGH HOLE-RIGHT ANGLE

• Number of Positions:

  8

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• PCB Hole Count:

  10

• Surface Mount:

  NO

• Switch Action:

  MAINTAINED

• Switch Function:

  DP3T

• Terminal Material:

  BRASS

• Termination Type:

  SOLDER
