MSC050SDA070B - Microsemi Corporation

MSC050SDA070B Details

• Manufacturer Part Number:

  MSC050SDA070B

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Transferred

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.80

• Date Of Intro:

  2018-05-10

• Manufacturer:

  Microsemi Corporation (now Microchip)

• Additional Feature:

  FREE WHEELING DIODE, HIGH RELIABILITY, LOW LEAKAGE CURRENT, LOW NOISE, PD-CASE, SNUBBER DIODE

• Application:

  ULTRA FAST SOFT RECOVERY

• Case Connection:

  CATHODE

• Configuration:

  SINGLE

• Diode Element Material:

  SILICON CARBIDE

• Diode Type:

  RECTIFIER DIODE

• Forward Voltage-Max (VF):

  1.8 V

• JEDEC-95 Code:

  TO-247

• JESD-30 Code:

  R-PSFM-T2

• Non-rep Pk Forward Current-Max:

  124 A

• Number of Elements:

  1

• Number of Phases:

  1

• Number of Terminals:

  2

• Operating Temperature-Max:

  175 °C

• Operating Temperature-Min:

  -55 °C

• Output Current-Max:

  88 A

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  FLANGE MOUNT

• Power Dissipation-Max:

  283 W

• Rep Pk Reverse Voltage-Max:

  700 V

• Reverse Current-Max:

  200 µA

• Reverse Test Voltage:

  700 V

• Surface Mount:

  NO

• Technology:

  SCHOTTKY

• Terminal Form:

  THROUGH-HOLE

• Terminal Position:

  SINGLE
