MSCDC50X1201AG - Microsemi Corporation

MSCDC50X1201AG Details

• Manufacturer Part Number:

  MSCDC50X1201AG

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Transferred

• Package Description:

  MODULE-12

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.80

• Manufacturer:

  Microsemi Corporation (now Microchip)

• Case Connection:

  ISOLATED

• Configuration:

  BRIDGE, 6 ELEMENTS

• Diode Element Material:

  SILICON CARBIDE

• Diode Type:

  BRIDGE RECTIFIER DIODE

• Forward Voltage-Max (VF):

  1.8 V

• JESD-30 Code:

  R-XUFM-X12

• Number of Elements:

  6

• Number of Phases:

  3

• Number of Terminals:

  12

• Operating Temperature-Max:

  175 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  50 A

• Package Body Material:

  UNSPECIFIED

• Package Shape:

  RECTANGULAR

• Package Style:

  FLANGE MOUNT

• Rep Pk Reverse Voltage-Max:

  1200 V

• Reverse Current-Max:

  200 µA

• Reverse Test Voltage:

  1200 V

• Surface Mount:

  NO

• Technology:

  SCHOTTKY

• Terminal Form:

  UNSPECIFIED

• Terminal Position:

  UPPER
