MSCSM170TAM45CT3AG - Microchip

MSCSM170TAM45CT3AG Details

• Manufacturer Part Number:

  MSCSM170TAM45CT3AG

• Part Life Cycle Code:

  Active

• Package Description:

  MODULE-28

• Country Of Origin:

  Philippines

• ECCN Code:

  EAR99

• Factory Lead Time:

  20 Weeks

• Manufacturer:

  Microchip Technology Inc

• YTEOL:

  19

• Case Connection:

  ISOLATED

• Configuration:

  COMPLEX

• DS Breakdown Voltage-Min:

  1700 V

• Drain Current-Max (ID):

  64 A

• Drain-source On Resistance-Max:

  0.045 Ω

• FET Technology:

  METAL-OXIDE SEMICONDUCTOR

• Feedback Cap-Max (Crss):

  10 pF

• JESD-30 Code:

  R-XUFM-X28

• Number of Elements:

  6

• Number of Terminals:

  28

• Operating Mode:

  ENHANCEMENT MODE

• Operating Temperature-Max:

  175 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  UNSPECIFIED

• Package Shape:

  RECTANGULAR

• Package Style:

  FLANGE MOUNT

• Polarity/Channel Type:

  N-CHANNEL

• Pulsed Drain Current-Max (IDM):

  130 A

• Surface Mount:

  NO

• Terminal Form:

  UNSPECIFIED

• Terminal Position:

  UPPER

• Transistor Application:

  SWITCHING

• Transistor Element Material:

  SILICON CARBIDE
