MSK5101-00 - MSK

MSK5101-00 Details

• Manufacturer Part Number:

  MSK5101-00

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Transferred

• Part Package Code:

  DFP

• Package Description:

  DFP-10

• Pin Count:

  10

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  MS Kennedy Corporation

• Adjustability:

  ADJUSTABLE

• Dropout Voltage1-Max:

  0.625 V

• Dropout Voltage1-Nom:

  0.35 V

• JESD-30 Code:

  S-CDSO-G10

• JESD-609 Code:

  e4

• Length:

  6.35 mm

• Line Regulation-Max (%/V):

  0.025

• Load Regulation-Max(%):

  1.2%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  10

• Operating Temperature TJ-Max:

  85 °C

• Operating Temperature TJ-Min:

  -40 °C

• Output Current1-Max:

  1.5 A

• Output Voltage1-Max:

  26 V

• Output Voltage1-Min:

  1.24 V

• Package Body Material:

  CERAMIC, METAL-SEALED COFIRED

• Package Code:

  SOP

• Package Equivalence Code:

  SOP10,.4

• Package Shape:

  SQUARE

• Package Style:

  SMALL OUTLINE

• Qualification Status:

  Not Qualified

• Regulator Type:

  ADJUSTABLE POSITIVE SINGLE OUTPUT LDO REGULATOR

• Seated Height-Max:

  2.159 mm

• Surface Mount:

  YES

• Technology:

  BIPOLAR

• Terminal Finish:

  GOLD

• Terminal Form:

  GULL WING

• Terminal Pitch:

  1.27 mm

• Terminal Position:

  DUAL

• Width:

  6.35 mm
