MSLPT5252AG4TR - TE Connectivity

MSLPT5252AG4TR Details

• Manufacturer Part Number:

  MSLPT5252AG4TR

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.90.40

• Factory Lead Time:

  6 Weeks, 6 Days

• Manufacturer:

  TE Connectivity

• YTEOL:

  9

• Actuator Material:

  POLYTETRA FLUOROETHYLENE

• Actuator Travel:

  0.25 mm

• Actuator Type:

  FLUSH TOP TYPE

• Additional Feature:

  LOW PROFILE

• Body Breadth:

  5.2 mm

• Body Color:

  BLACK

• Body Height:

  0.8 mm

• Body Length or Diameter:

  5.2 mm

• Center Contact Material:

  STAINLESS STEEL

• Center Contact Plating:

  SILVER

• Circuit Configuration:

  1X1

• Contact Current(AC)-Max:

  0.05 A

• Contact Current(DC)-Max:

  0.05 A

• Contact (DC) Max Rating R Load:

  0.05A@12VDC

• Contact Resistance:

  0.1 mΩ

• Contact Voltage(DC)-Max:

  12 V

• Dielectric Withstand Volts:

  250VAC V

• Electrical Life:

  200000 Cycle(s)

• End Contact Material:

  STAINLESS STEEL

• End Contact Plating:

  SILVER OVER NICKEL

• Housing Material:

  POLYETHYLENE

• Insulation Resistance:

  100000000 Ω

• Insulator Material:

  THERMOPLASTIC

• Mounting Feature:

  PANEL MOUNT

• Number of Switches:

  1

• Operating Force-Max:

  2.548 N

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -25 °C

• Packing Method:

  TR

• Surface Mount:

  NO

• Switch Action:

  MOMENTARY

• Switch Function:

  SPST

• Switch Type:

  KEYPAD SWITCH

• Terminal Material:

  COPPER ALLOY

• Termination Type:

  SOLDER
