MSS3-Q-T/R - Diptronics

MSS3-Q-T/R Details

• Manufacturer Part Number:

  MSS3-Q-T/R

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.90.50

• Manufacturer:

  Diptronics Manufacturing Inc

• YTEOL:

  6

• Actuator Length:

  0.059 inch

• Actuator Type:

  SLIDE

• Body Breadth:

  2.6 mm

• Body Height:

  1.4 mm

• Body Length or Diameter:

  6.7 mm

• Contact Current(DC)-Max:

  0.025 A

• Contact (DC) Max Rating R Load:

  0.025A@24VDC

• Contact Resistance:

  0.07 mΩ

• Contact Voltage(DC)-Max:

  24 V

• Electrical Life:

  10000 Cycle(s)

• Insulation Resistance:

  100000000 Ω

• Mounting Feature:

  SURFACE MOUNT-RIGHT ANGLE

• Number of Positions:

  2

• Operating Force-Max:

  2.45 N

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -20 °C

• Packing Method:

  TR

• Surface Mount:

  NO

• Switch Action:

  LATCHED

• Switch Function:

  SPDT

• Switch Type:

  SLIDE SWITCH

• Termination Type:

  SOLDER
