MSW-2-20 - Mini-Circuits

MSW-2-20 Details

• Manufacturer Part Number:

  MSW-2-20

• Pbfree Code:

  No

• Part Life Cycle Code:

  Active

• Package Description:

  CASE XX211-1, 8 PIN

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.70.00

• Manufacturer:

  Mini-Circuits

• YTEOL:

  4.43

• 1dB Compression Point:

  25 dBm

• Characteristic Impedance:

  50 Ω

• Construction:

  COMPONENT

• Input Power-Max (CW):

  31 dBm

• Insertion Loss-Max:

  1.3 dB

• Isolation-Min:

  20 dB

• JESD-609 Code:

  e0

• Mounting Feature:

  SURFACE MOUNT

• Number of Functions:

  1

• Number of Terminals:

  8

• Operating Frequency-Max:

  2000 MHz

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Equivalence Code:

  SOP8,.25

• Port Termination:

  REFLECTIVE

• RF/Microwave Device Type:

  SPDT

• Surface Mount:

  YES

• Technology:

  GAAS

• Terminal Finish:

  Tin/Lead (Sn/Pb)

• VSWR-Max:

  1.4
