MT29F32G08ABCABH1-10ITZ:A - Micron

MT29F32G08ABCABH1-10ITZ:A Details

• Manufacturer Part Number:

  MT29F32G08ABCABH1-10ITZ:A

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  VBGA-100

• ECCN Code:

  EAR99

• HTS Code:

  8542.32.00.51

• Factory Lead Time:

  10 Weeks

• Manufacturer:

  Micron Technology Inc

• Clock Frequency-Max (fCLK):

  83 MHz

• Endurance:

  80000 Write/Erase Cycles

• JESD-30 Code:

  R-PBGA-B100

• Length:

  18 mm

• Memory Density:

  34359738368 bit

• Memory IC Type:

  FLASH

• Memory Width:

  8

• Number of Functions:

  1

• Number of Terminals:

  100

• Number of Words:

  4294967296 words

• Number of Words Code:

  4000000000

• Operating Mode:

  SYNCHRONOUS

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Organization:

  4GX8

• Output Characteristics:

  3-STATE

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  VBGA

• Package Equivalence Code:

  BGA100,10X15,40

• Package Shape:

  RECTANGULAR

• Package Style:

  GRID ARRAY, VERY THIN PROFILE

• Parallel/Serial:

  SERIAL

• Programming Voltage:

  3.3 V

• Qualification Status:

  Not Qualified

• Seated Height-Max:

  1 mm

• Serial Bus Type:

  ONFI 2.2

• Standby Current-Max:

  0.00005 A

• Supply Current-Max:

  0.029 mA

• Supply Voltage-Max (Vsup):

  3.6 V

• Supply Voltage-Min (Vsup):

  2.7 V

• Supply Voltage-Nom (Vsup):

  3.3 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  INDUSTRIAL

• Terminal Form:

  BALL

• Terminal Pitch:

  1 mm

• Terminal Position:

  BOTTOM

• Type:

  SLC NAND TYPE

• Width:

  12 mm

• Write Cycle Time-Max (tWC):

  0.00002 ms

• Write Protection:

  HARDWARE
