MTA406P - TE Connectivity

MTA406P Details

• Manufacturer Part Number:

  MTA406P

• Brand Name:

  Alcoswitch

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.90.65

• Factory Lead Time:

  23 Weeks

• Manufacturer:

  TE Connectivity

• YTEOL:

  0

• Actuator Angle:

  24 deg

• Actuator Finish:

  CHROME

• Actuator Length:

  0.41 inch

• Actuator Material:

  BRASS

• Actuator Type:

  LONG BAT

• Body Breadth:

  13 mm

• Body Color:

  GREEN

• Body Height:

  12.5 mm

• Body Length or Diameter:

  22.6 mm

• Bushing Length:

  0.32 inch

• Bushing Type:

  1/4-40

• Center Contact Plating:

  GOLD OVER SILVER

• Contact (AC) Max Rating R Load:

  6A@125VAC

• Contact Current(AC)-Max:

  6 A

• Contact Current(DC)-Max:

  6 A

• Contact (DC) Max Rating R Load:

  4A@28VDC

• Contact Function:

  ON-OFF-ON

• Contact Resistance:

  0.01 mΩ

• Contact Timing:

  BREAK-BEFORE-MAKE

• Contact Voltage(AC)-Max:

  125 V

• Contact Voltage(DC)-Max:

  28 V

• Dielectric Withstand Volts:

  1500 V

• Electrical Life:

  60000 Cycle(s)

• End Contact Material:

  COPPER ALLOY

• End Contact Plating:

  GOLD OVER SILVER

• Insulation Resistance:

  1000000000 Ω

• Insulator Material:

  THERMOSET 94V-0

• JESD-609 Code:

  e4

• Mounting Feature:

  PANEL MOUNT

• Operating Force-Max:

  14.71 N

• Operating Temperature-Max:

  80 °C

• Operating Temperature-Min:

  -20 °C

• Sealing:

  EPOXY TERMINAL SEALED

• Surface Mount:

  NO

• Switch Action:

  LATCHED

• Switch Function:

  4PDT

• Switch Type:

  TOGGLE SWITCH

• Terminal Finish:

  GOLD

• Termination Type:

  WIRE
