MTC1S2405MC-R13 - Murata Electronics

MTC1S2405MC-R13 Details

• Manufacturer Part Number:

  MTC1S2405MC-R13

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  PACKAGE-6

• ECCN Code:

  EAR99

• Manufacturer:

  Murata Manufacturing Co Ltd

• YTEOL:

  9

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  UL, ANSI, AAMI

• Efficiency (Main Output):

  76.5%

• Input Voltage-Max:

  36 V

• Input Voltage-Min:

  18 V

• Input Voltage-Nom:

  24 V

• JESD-30 Code:

  R-XDMA-X6

• JESD-609 Code:

  e4

• Length:

  14.99 mm

• Line Regulation-Max:

  0.2%

• Load Regulation-Max:

  0.2%

• Moisture Sensitivity Level:

  2

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  6

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  0.2 A

• Output Voltage-Max:

  5.5 V

• Output Voltage-Min:

  4.5 V

• Output Voltage-Nom:

  5 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  DMA

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Peak Reflow Temperature (Cel):

  245

• Protections:

  SHORT CIRCUIT

• Ripple Voltage (Main Out):

  0.017675 Vrms

• Screening Level:

  IEC 60601-1, One MOPP, IEC 60601-1, Two MOOP

• Seated Height-Max:

  11.75 mm

• Surface Mount:

  YES

• Technology:

  HYBRID

• Terminal Finish:

  Gold (Au) - with Nickel (Ni) barrier

• Terminal Form:

  UNSPECIFIED

• Terminal Position:

  DUAL

• Total Power Output-Max:

  1 W

• Trim/Adjustable Output:

  YES

• Warm-up Time:

  0.014 s

• Width:

  14.22 mm
