MVA-1000+ - Mini-Circuits

MVA-1000+ Details

• Manufacturer Part Number:

  MVA-1000+

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  ROHS COMPLIANT, CASE GP1212

• Reach Compliance Code:

  Not Compliant

• ECCN Code:

  EAR99

• Manufacturer:

  Mini-Circuits

• YTEOL:

  5.9

• Attenuation-Nom:

  13 dB

• Characteristic Impedance:

  50 Ω

• Construction:

  COMPONENT

• Input Power-Max (CW):

  20 dBm

• Insertion Loss-Max:

  4.7 dB

• JESD-609 Code:

  e4

• Mounting Feature:

  SURFACE MOUNT

• Number of Terminals:

  8

• Operating Frequency-Max:

  1000 MHz

• Operating Frequency-Min:

  50 MHz

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  METAL

• Package Equivalence Code:

  LCC8,.35SQ,75

• Power Supplies:

  5 V

• RF/Microwave Device Type:

  VARIABLE ATTENUATOR

• Supply Current-Max:

  3 mA

• Surface Mount:

  YES

• Terminal Finish:

  Gold (Au) - with Nickel (Ni) barrier

• VSWR-Max:

  1.22
