MXL15KP33CA - Microsemi Corporation

MXL15KP33CA Details

• Manufacturer Part Number:

  MXL15KP33CA

• Pbfree Code:

  No

• Part Life Cycle Code:

  Transferred

• Package Description:

  PLASTIC, CASE 5A, 2 PIN

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.50

• Manufacturer:

  Microsemi Corporation (now Microchip)

• Additional Feature:

  HIGH RELIABILITY

• Breakdown Voltage-Min:

  36.7 V

• Case Connection:

  ISOLATED

• Configuration:

  SINGLE

• Diode Element Material:

  SILICON

• Diode Type:

  TRANS VOLTAGE SUPPRESSOR DIODE

• JEDEC-95 Code:

  DO-204AR

• JESD-30 Code:

  O-PALF-W2

• JESD-609 Code:

  e0

• Moisture Sensitivity Level:

  1

• Non-rep Peak Rev Power Dis-Max:

  15000 W

• Number of Elements:

  1

• Number of Terminals:

  2

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -65 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  ROUND

• Package Style:

  LONG FORM

• Polarity:

  BIDIRECTIONAL

• Power Dissipation-Max:

  1.56 W

• Qualification Status:

  Not Qualified

• Reference Standard:

  MIL-19500

• Rep Pk Reverse Voltage-Max:

  33 V

• Surface Mount:

  NO

• Technology:

  AVALANCHE

• Terminal Finish:

  Tin/Lead (Sn/Pb)

• Terminal Form:

  WIRE

• Terminal Position:

  AXIAL
