The maximum number of erase cycles for the N25Q256A13ESF40F is 100,000 cycles.
To handle the hold condition during a write or erase operation, the HOLD# pin should be asserted low to pause the operation. Once the hold condition is removed, the operation will resume from where it was paused.
The recommended power-up sequence is to apply VCC first, followed by VPP (if used), and then the clock signal. This ensures proper device initialization and prevents latch-up conditions.
The optimal value for the VPP voltage depends on the specific application and operating conditions. As a general guideline, Micron recommends a VPP voltage of 3.3V ± 0.3V for the N25Q256A13ESF40F.
The WP# (Write Protect) pin is used to prevent accidental writes or erases to the device. When the WP# pin is asserted low, the device is write-protected, and any write or erase operations will be ignored.
