NA5814-AL Frequently Asked Questions (FAQs)

• What is the recommended PCB land pattern for NA5814-AL?
  Coilcraft provides a recommended PCB land pattern in their application note AN-40, which can be found on their website. The land pattern is designed to ensure optimal performance and reliability of the inductor.
• How do I handle the NA5814-AL inductor during PCB assembly to prevent damage?
  To prevent damage, handle the inductor by the body, not the leads. Avoid bending or flexing the leads, and do not touch the component with bare hands as the oils from skin can cause damage. Use a vacuum pickup or tweezers to handle the component during PCB assembly.
• What is the thermal derating of the NA5814-AL inductor?
  The thermal derating of the NA5814-AL inductor is typically 1.5% per degree Celsius above 40°C. This means that the inductor's current rating decreases as the temperature increases. Consult the datasheet or Coilcraft's application notes for more information on thermal derating.
• Can I use the NA5814-AL inductor in a high-vibration environment?
  The NA5814-AL inductor is designed to withstand moderate vibration levels. However, if the application involves high vibration levels, it's recommended to use a more robust inductor or take additional measures to secure the component, such as using a vibration-dampening material or a more secure mounting method.
• How do I determine the saturation current of the NA5814-AL inductor?
  The saturation current of the NA5814-AL inductor can be determined by consulting the datasheet or by using Coilcraft's online inductor selection tool. The tool allows you to enter the desired operating conditions and provides the saturation current and other relevant parameters.
