NC12S0A0H06PNFA - Delta Electronics

NC12S0A0H06PNFA Details

• Manufacturer Part Number:

  NC12S0A0H06PNFA

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  MODULE

• Package Description:

  PACKAGE-9

• Pin Count:

  8

• ECCN Code:

  EAR99

• Manufacturer:

  Delta Electronics Inc

• YTEOL:

  0

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  CE, TUV, UL

• Control Mode:

  VOLTAGE-MODE

• Efficiency (Main Output):

  91%

• Input Voltage-Max:

  13.8 V

• Input Voltage-Min:

  10.2 V

• Input Voltage-Nom:

  12 V

• JESD-30 Code:

  R-XDMA-P9

• Length:

  30.5 mm

• Line Regulation-Max:

  2%

• Load Regulation-Max:

  1%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  9

• Operating Temperature-Max:

  47 °C

• Output Current-Max:

  6 A

• Output Voltage-Max:

  5 V

• Output Voltage-Min:

  0.9 V

• Output Voltage-Nom:

  0.9 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  DMA

• Package Shape:

  RECTANGULAR

• Package Style:

  MODULE

• Protections:

  OUTPUT OVER CURRENT; OUTPUT OVER VOLTAGE

• Qualification Status:

  Not Qualified

• Seated Height-Max:

  12.35 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Form:

  PIN/PEG

• Terminal Position:

  DUAL

• Total Power Output-Max:

  30 W

• Trim/Adjustable Output:

  YES

• Warm-up Time:

  0.01 s

• Width:

  15.5 mm
