NC12S0A0V60PNFA - Delta Electronics

NC12S0A0V60PNFA Details

• Manufacturer Part Number:

  NC12S0A0V60PNFA

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  MODULE

• Package Description:

  PACKAGE-32/31

• Pin Count:

  16

• ECCN Code:

  EAR99

• Manufacturer:

  Delta Electronics Inc

• YTEOL:

  0

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  CE, TUV, UL

• Control Mode:

  VOLTAGE-MODE

• Efficiency (Main Output):

  95%

• Input Voltage-Max:

  12.6 V

• Input Voltage-Min:

  11.04 V

• Input Voltage-Nom:

  12 V

• JESD-30 Code:

  R-XSMA-T32/31

• Length:

  81.3 mm

• Line Regulation-Max:

  0.2%

• Load Regulation-Max:

  1.5%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  31

• Output Current-Max:

  60 A

• Output Voltage-Max:

  5 V

• Output Voltage-Min:

  0.9 V

• Output Voltage-Nom:

  0.9 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  SMA

• Package Shape:

  RECTANGULAR

• Package Style:

  MODULE

• Protections:

  OUTPUT OVER CURRENT; OUTPUT OVER VOLTAGE; THERMAL

• Qualification Status:

  Not Qualified

• Seated Height-Max:

  32.5 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Form:

  THROUGH-HOLE

• Terminal Pitch:

  2.54 mm

• Terminal Position:

  SINGLE

• Total Power Output-Max:

  300 W

• Trim/Adjustable Output:

  YES

• Warm-up Time:

  0.03 s

• Width:

  13.5 mm
