NC3FDM3-H-B - Neutrik

NC3FDM3-H-B Details

• Manufacturer Part Number:

  NC3FDM3-H-B

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.10

• Manufacturer:

  Neutrik USA Inc

• Body Breadth:

  1.22 inch

• Body Depth:

  1.051 inch

• Body Length:

  1.024 inch

• Body/Shell Style:

  RECEPTACLE

• Connector Type:

  XLR

• Contact Finish Mating:

  AG ON NI

• Contact Gender:

  FEMALE

• Contact Material:

  BRONZE

• Contact Resistance:

  5 mΩ

• Contact Style:

  RND PIN-SKT

• Dielectric Withstanding Voltage:

  1500VDC V

• Durability:

  1000 Cycles

• Insertion Force-Max:

  20.016 N

• Insulation Resistance:

  10000000000 Ω

• Mounting Option 1:

  M3

• Mounting Option 2:

  LOCKING

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD

• Number Of Connectors:

  ONE

• Number of Poles:

  3

• Number of Ports:

  1

• Operating Temperature-Max:

  80 °C

• Operating Temperature-Min:

  -30 °C

• Plating Thickness:

  79u inch

• Polarization Key:

  POLARIZED KEY

• Rated Current (Signal):

  6 A

• Reference Standard:

  UL

• Shell Finish:

  NICKEL

• Shell Material:

  ZINC ALLOY

• Terminal Length:

  0.138 inch

• Termination Type:

  SOLDER

• Withdrawl Force-Min:

  20.016 N
