NC6-P107-12 - TE Connectivity

Description: Barrier Terminal Blocks DUAL .375" 12P 12-22

Download NC6-P107-12 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
NC6-P107-12 - TE Connectivity - PCB symbol
click to zoom
PCB Footprints
NC6-P107-12 - TE Connectivity PCB footprint - Other - Other - NC6-P107-12-1
click to zoom
3D Models
NC6-P107-12 - TE Connectivity - 3D model - Other - NC6-P107-12-1
click to zoom

NC6-P107-12 Details

  • Manufacturer Part Number:

    NC6-P107-12

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Package Description:

    ROHS COMPLIANT

  • ECCN Code:

    EAR99

  • HTS Code:

    8536.90.40.00

  • Manufacturer:

    TE Connectivity

  • YTEOL:

    6.81

  • Additional Feature:

    POLYAMIDE, UL 94V-0

  • Fastening Method:

    SCREW

  • Mounting Type:

    BOARD

  • Number of Decks:

    1

  • Number of Rows:

    1

  • Number of Ways:

    12

  • Rated Current:

    20 A

  • Rated Voltage:

    300 V

  • Safety Approval:

    UL

  • Terminal and Terminal Block Type:

    BARRIER STRIP TERMINAL BLOCK

  • Wire Cross Section:

    3 mm2

  • Wire Gauge:

    12 AWG

NC6-P107-12 Frequently Asked Questions (FAQs)

  • The recommended torque for the screw terminals of NC6-P107-12 is 0.8 Nm to 1.2 Nm (7 in-lbs to 10 in-lbs).
  • Yes, the NC6-P107-12 is designed to withstand high-vibration environments. It meets the IEC 61373 vibration standard, which ensures reliable performance in harsh conditions.
  • The NC6-P107-12 has a IP67 rating, which means it is protected against dust and water ingress. However, it's recommended to use additional sealing or protective measures for extended outdoor exposure.
  • The NC6-P107-12 can operate in temperatures ranging from -40°C to 125°C (-40°F to 257°F).
  • While the NC6-P107-12 is designed for 12 AWG wires, it can accommodate wire sizes between 10 AWG and 14 AWG. However, the wire stripping length and insulation diameter may need to be adjusted accordingly.

Trust Checks

This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

NC6-P107-12 Overview

Use the download button to access the NC6-P107-12 schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like NC6-P, or try a keyword search, such as Terminals and Terminal Blocks
