NCA9306GSX - Nexperia

NCA9306GSX Details

• Manufacturer Part Number:

  NCA9306GSX

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  XSON-8

• Country Of Origin:

  Malaysia

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  Nexperia

• YTEOL:

  8

• Delay-Max:

  3.82 ns

• Interface IC Type:

  VOLTAGE LEVEL TRANSLATOR

• JESD-30 Code:

  R-PDSO-N8

• Length:

  1.35 mm

• Moisture Sensitivity Level:

  1

• Number of Bits:

  2

• Number of Functions:

  1

• Number of Terminals:

  8

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Output Characteristics:

  OPEN-DRAIN

• Output Polarity:

  TRUE

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  VSON

• Package Equivalence Code:

  SOLCC8,.04,14

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE, ULTRA THIN PROFILE

• Peak Reflow Temperature (Cel):

  260

• Seated Height-Max:

  0.35 mm

• Supply Voltage-Max:

  5 V

• Supply Voltage-Min:

  0.95 V

• Supply Voltage-Nom:

  1.2 V

• Surface Mount:

  YES

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  0.35 mm

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  40

• Width:

  1 mm
