NCD57000DWR2G - onsemi

Description: High Current Output(+4/-6 A) at IGBT Miller Plateau Voltages; Short Propagation Delays with Accurate Matching; DESAT with Soft Turn Off; Active Miller Clamp and Negative Gate Voltage; High Transient & Electromagnetic Immunity; 5 kV Galvanic Isolation

Download NCD57000DWR2G Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
NCD57000DWR2G - onsemi PCB footprint - Small Outline Packages - Small Outline Packages - SOIC-16 WB CASE 751G-03 ISSUE D
click to zoom
3D Models
NCD57000DWR2G - onsemi  - 3D model - Small Outline Packages - SOIC-16 WB CASE 751G-03 ISSUE D
click to zoom

NCD57000DWR2G Details

  • Manufacturer Part Number:

    NCD57000DWR2G

  • Brand Name:

    onsemi

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Part Package Code:

    SOIC-16W

  • Package Description:

    SOIC-16

  • Manufacturer Package Code:

    751G-03

  • Country Of Origin:

    Philippines

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Factory Lead Time:

    26 Weeks

  • Date Of Intro:

    2018-12-11

  • Manufacturer:

    onsemi

  • YTEOL:

    6

  • High Side Driver:

    NO

  • Input Characteristics:

    DIFFERENTIAL

  • Interface IC Type:

    BUFFER OR INVERTER BASED MOSFET DRIVER

  • JESD-30 Code:

    R-PDSO-G16

  • Length:

    10.3 mm

  • Moisture Sensitivity Level:

    1

  • Number of Functions:

    1

  • Number of Terminals:

    16

  • Operating Temperature-Max:

    125 °C

  • Operating Temperature-Min:

    -40 °C

  • Output Characteristics:

    OPEN-DRAIN

  • Output Peak Current Limit-Nom:

    7.8 A

  • Output Polarity:

    TRUE

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    SOP

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE

  • Peak Reflow Temperature (Cel):

    260

  • Seated Height-Max:

    2.65 mm

  • Supply Voltage-Max:

    5.5 V

  • Supply Voltage-Nom:

    5 V

  • Supply Voltage1-Max:

    24 V

  • Supply Voltage1-Nom:

    15 V

  • Surface Mount:

    YES

  • Temperature Grade:

    AUTOMOTIVE

  • Terminal Finish:

    Nickel/Gold/Palladium (Ni/Au/Pd)

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    1.27 mm

  • Terminal Position:

    DUAL

  • Time@Peak Reflow Temperature-Max (s):

    30

  • Turn-off Time:

    0.09 µs

  • Turn-on Time:

    0.09 µs

  • Width:

    7.5 mm

NCD57000DWR2G Frequently Asked Questions (FAQs)

  • A recommended PCB layout for the NCD57000DWR2G involves placing the device near a thermal pad or heat sink, using a 2-layer or 4-layer board with a solid ground plane, and minimizing the distance between the device and the thermal pad or heat sink.
  • To ensure proper biasing, connect the VCC pin to a stable voltage source, and the GND pin to a solid ground plane. Also, ensure that the input voltage is within the recommended operating range of 2.7V to 5.5V.
  • The maximum current rating for the NCD57000DWR2G is 1A. To avoid exceeding this rating, ensure that the total current drawn from the device does not exceed 1A, and use a suitable current-limiting resistor or fuse to prevent overcurrent conditions.
  • To troubleshoot issues with the NCD57000DWR2G, check the input voltage and current, ensure proper PCB layout and thermal management, and verify that the device is properly biased. Also, check for any signs of physical damage or electrical overstress.
  • Yes, the NCD57000DWR2G can operate in high-temperature environments up to 125°C. However, ensure that the device is properly heat-sinked, and consider using a thermal interface material to improve heat transfer. Also, derate the device's performance according to the temperature derating curve in the datasheet.
