NCP1012AP133G - onsemi

Description: Obsolete - High Voltage Switching Regulator for Offline SMPS

Download NCP1012AP133G Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
NCP1012AP133G - onsemi PCB footprint - Dual-In-Line Packages - Dual-In-Line Packages - PDIP−7 (PDIP−8 LESS PIN 6) CASE 626A ISSUE C
click to zoom
3D Models
NCP1012AP133G - onsemi  - 3D model - Dual-In-Line Packages - PDIP−7 (PDIP−8 LESS PIN 6) CASE 626A ISSUE C
click to zoom

NCP1012AP133G Details

  • Manufacturer Part Number:

    NCP1012AP133G

  • Brand Name:

    onsemi

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Obsolete

  • Part Package Code:

    PDIP-7 (PDIP-8 LESS PIN 6)

  • Pin Count:

    7

  • Manufacturer Package Code:

    626A-01

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Manufacturer:

    onsemi

  • YTEOL:

    0

  • Analog IC - Other Type:

    SWITCHING REGULATOR

  • Control Mode:

    CURRENT-MODE

  • Control Technique:

    PULSE WIDTH MODULATION

  • Input Voltage-Nom:

    8 V

  • JESD-30 Code:

    R-PDIP-T7

  • JESD-609 Code:

    e3

  • Length:

    9.78 mm

  • Number of Functions:

    1

  • Number of Terminals:

    7

  • Output Current-Max:

    1 A

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    DIP

  • Package Equivalence Code:

    DIP7/8,.3

  • Package Shape:

    RECTANGULAR

  • Package Style:

    IN-LINE

  • Qualification Status:

    Not Qualified

  • Seated Height-Max:

    4.45 mm

  • Surface Mount:

    NO

  • Switcher Configuration:

    SINGLE

  • Switching Frequency-Max:

    143 kHz

  • Terminal Finish:

    MATTE TIN

  • Terminal Form:

    THROUGH-HOLE

  • Terminal Pitch:

    2.54 mm

  • Terminal Position:

    DUAL

  • Width:

    7.62 mm
