Description:Current-Mode Fixed Frequency Operation (65 & 100 kHz) - 130 kHz for B version only; Peak Current: NCP1075A/B = 400 mA; 2nd Level Current Protection; Over Power Protection; Adjustable Brown-out Protection and OVP; Frequency Jittering (including during frequency foldback mode); 300 µA No Load Power Consumption; Frequency Foldback Operation; Auto-Recovery Output Short Circuit Protection with Timer-Based Detection; Dynamic Self-Supply (DSS); Skip-Cycle Operation at Low Peak Current; Integrated 700 V MOSFET with
The maximum input voltage that can be applied to the NCP1075AAP065G is 18V, although the recommended maximum input voltage is 15V for optimal performance and reliability.
To ensure the stability of the output voltage, it is recommended to use a minimum output capacitance of 10uF with an ESR of 1 ohm or less, and to place the capacitor close to the output pin of the regulator.
The maximum output current that the NCP1075AAP065G can deliver is 5A, although the maximum output current may be limited by the input voltage, output voltage, and thermal considerations.
To protect the NCP1075AAP065G from overheating, it is recommended to provide adequate heat sinking, such as a copper plane or a heat sink, and to ensure good airflow around the device. The maximum junction temperature of the device is 150°C.
Yes, the NCP1075AAP065G is qualified to AEC-Q100 Grade 1, which makes it suitable for use in high-reliability and automotive applications. However, it is recommended to consult the datasheet and application notes for specific requirements and guidelines.
Trust Checks
This model has been built in collaboration with the manufacturer.
Manufacturer Collaborated
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
NCP1075AAP065G Overview
Use the download button to access the NCP1075AAP065G schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like NCP10,
or try a keyword search, such as Switching Regulator or Controllers
