Part Image

NCP11187A100PG - onsemi

Description: Internal rugged 0.7 Ω Typ.RDS(on) 800 V MOSFET and Built-in HV current source for start up; mWSaverTM Technology and Frequency Foldback; Fsw options: 65/100/130 kHz; Line compensation for constant maximum over load limiting; Brown In/Out Protection & Line Over Voltage Protection; Various Protections • VDD Over Voltage Protection (VDD-OVP) • Over Load Protection (OLP) • Current Sensing Resistor Short Protection (CSSP) • Abnormal Over Current Protection (AOCP) • Thermal Shutdown Protection (TSD) • VDD Under-V

Download NCP11187A100PG Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
NCP11187A100PG - onsemi PCB footprint - Other - Other - PDIP−7 (PDIP−8 LESS PIN 6) CASE 626A
click to zoom
3D Models
NCP11187A100PG - onsemi  - 3D model - Other - PDIP−7 (PDIP−8 LESS PIN 6) CASE 626A
click to zoom

NCP11187A100PG Details

  • Manufacturer Part Number:

    NCP11187A100PG

  • Brand Name:

    onsemi

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Part Package Code:

    PDIP-7

  • Package Description:

    DIP-8/7

  • Manufacturer Package Code:

    626A-01

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Factory Lead Time:

    20 Weeks

  • Date Of Intro:

    2018-07-30

  • Manufacturer:

    onsemi

  • YTEOL:

    5

  • Analog IC - Other Type:

    SWITCHING CONTROLLER

  • Control Mode:

    CURRENT-MODE

  • Control Technique:

    PULSE WIDTH MODULATION

  • Input Voltage-Max:

    3 V

  • Input Voltage-Min:

    1 V

  • Input Voltage-Nom:

    15 V

  • JESD-30 Code:

    R-PDIP-T7

  • Length:

    9.59 mm

  • Number of Functions:

    1

  • Number of Terminals:

    7

  • Operating Temperature-Max:

    125 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    DIP

  • Package Equivalence Code:

    DIP7/8,.3

  • Package Shape:

    RECTANGULAR

  • Package Style:

    IN-LINE

  • Seated Height-Max:

    5.33 mm

  • Supply Voltage-Nom (Vsup):

    15 V

  • Surface Mount:

    NO

  • Switching Frequency-Max:

    100 kHz

  • Temperature Grade:

    AUTOMOTIVE

  • Terminal Form:

    THROUGH-HOLE

  • Terminal Pitch:

    2.54 mm

  • Terminal Position:

    DUAL

  • Width:

    7.62 mm

NCP11187A100PG Frequently Asked Questions (FAQs)

  • The maximum input voltage is 18V, but it's recommended to keep it below 15V for optimal performance and to prevent overheating.
  • To ensure stability, a minimum output capacitance of 10uF with an ESR (Equivalent Series Resistance) of less than 1 ohm is recommended. Additionally, the output capacitor should be placed as close as possible to the output pin.
  • The thermal shutdown temperature is typically around 150°C, but it may vary depending on the specific device and operating conditions.
  • The device is rated for a junction temperature (Tj) of up to 150°C, but the maximum operating temperature is limited by the package thermal resistance and the power dissipation. It's recommended to consult the thermal derating curves in the datasheet to ensure safe operation.
  • The power dissipation (PD) can be calculated using the formula: PD = (VIN - VOUT) x IOUT, where VIN is the input voltage, VOUT is the output voltage, and IOUT is the output current.

Trust Checks

This model has been built in collaboration with the manufacturer.
Manufacturer Collaborated
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

NCP11187A100PG Overview

Use the download button to access the NCP11187A100PG schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like NCP11, or try a keyword search, such as Switching Regulator or Controllers
