NCP1341B1DR2G - onsemi

Description: Obsolete - Quasi-Resonant Flyback Controller with Valley Lock-Out Switching

Download NCP1341B1DR2G Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
NCP1341B1DR2G - onsemi PCB footprint - Small Outline Packages - Small Outline Packages - SOIC-8 NB CASE 751-07 ISSUE AK
click to zoom
3D Models
NCP1341B1DR2G - onsemi  - 3D model - Small Outline Packages - SOIC-8 NB CASE 751-07 ISSUE AK
click to zoom

NCP1341B1DR2G Details

  • Manufacturer Part Number:

    NCP1341B1DR2G

  • Brand Name:

    onsemi

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Obsolete

  • Part Package Code:

    SOIC-8

  • Manufacturer Package Code:

    751-07

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Manufacturer:

    onsemi

  • YTEOL:

    0

  • Analog IC - Other Type:

    SWITCHING CONTROLLER

  • Control Mode:

    CURRENT-MODE

  • Control Technique:

    RESONANT CONTROL

  • Input Voltage-Max:

    28 V

  • Input Voltage-Min:

    9 V

  • Input Voltage-Nom:

    12 V

  • JESD-30 Code:

    R-PDSO-G8

  • JESD-609 Code:

    e3

  • Length:

    4.9 mm

  • Moisture Sensitivity Level:

    1

  • Number of Functions:

    1

  • Number of Terminals:

    8

  • Operating Temperature-Max:

    125 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    SOP

  • Package Equivalence Code:

    SOP8,.25

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE

  • Peak Reflow Temperature (Cel):

    260

  • Seated Height-Max:

    1.75 mm

  • Supply Current-Max (Isup):

    1.5 mA

  • Surface Mount:

    YES

  • Switcher Configuration:

    BUCK-BOOST

  • Switching Frequency-Max:

    25 kHz

  • Temperature Grade:

    AUTOMOTIVE

  • Terminal Finish:

    MATTE TIN

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    1.27 mm

  • Terminal Position:

    DUAL

  • Time@Peak Reflow Temperature-Max (s):

    30

  • Width:

    3.9 mm

NCP1341B1DR2G Frequently Asked Questions (FAQs)

  • A good PCB layout for the NCP1341B1DR2G should prioritize thermal management, with a solid ground plane and thermal vias to dissipate heat. The input and output capacitors should be placed close to the IC, and the feedback network should be routed to minimize noise and parasitic inductance.
  • To ensure stability, follow the recommended component values and PCB layout guidelines. Additionally, ensure that the output capacitor has a low ESR, and the feedback network is properly compensated. If oscillations occur, try adding a small capacitor (e.g., 10nF) in parallel with the output capacitor to dampen the oscillation.
  • The NCP1341B1DR2G is rated for operation up to 125°C ambient temperature, but it's recommended to derate the output power and current to ensure reliable operation at high temperatures. Consult the datasheet for thermal derating curves and guidelines.
  • Yes, the NCP1341B1DR2G is qualified for automotive and high-reliability applications. It meets the AEC-Q100 standard for automotive grade devices, and onsemi provides additional documentation and support for these applications. However, it's essential to follow the recommended design and testing guidelines to ensure the device meets the specific requirements of your application.
  • To troubleshoot issues with the NCP1341B1DR2G, start by verifying the input voltage, output voltage, and current. Check the PCB layout and component values against the recommended design guidelines. Use an oscilloscope to inspect the output voltage and current waveforms, and look for signs of oscillation or instability. Consult the datasheet and application notes for troubleshooting guides and FAQs.
