A good PCB layout for the NCP1650DR2G involves keeping the input and output capacitors close to the device, using a solid ground plane, and minimizing the length of the input and output traces. Additionally, it's recommended to use a separate power plane for the device and to decouple the input and output with 10uF and 1uF capacitors, respectively.
To ensure stability, make sure to follow the recommended PCB layout, use a sufficient output capacitor (at least 10uF), and keep the input voltage within the recommended range. Additionally, avoid using long input and output traces, and decouple the input and output with capacitors as mentioned earlier.
The NCP1650DR2G can handle input voltages up to 18V, but it's recommended to keep the input voltage within the recommended range of 7V to 15V for optimal performance and reliability.
The NCP1650DR2G is rated for operation up to 125°C, but it's recommended to derate the output current and input voltage at higher temperatures to ensure reliability and prevent overheating.
The output voltage of the NCP1650DR2G can be calculated using the formula: Vout = (R1/R2) * (Vin - Vref), where R1 and R2 are the feedback resistors, Vin is the input voltage, and Vref is the internal reference voltage (typically 1.25V).
Trust Checks
This model has been built in collaboration with the manufacturer.
Manufacturer Collaborated
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
NCP1650DR2G Overview
Use the download button to access the NCP1650DR2G schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like NCP16,
or try a keyword search, such as Switching Regulator or Controllers
