NCP45525IMNTWG-H - onsemi

Description: Power Switch/Driver 1:1 N-Channel 6A 8-DFN (2x2)

Download NCP45525IMNTWG-H Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
NCP45525IMNTWG-H - onsemi PCB footprint - Other - Other - DFN8 2x2, 0.5P CASE 506CC ISSUE A
click to zoom
3D Models
NCP45525IMNTWG-H - onsemi  - 3D model - Other - DFN8 2x2, 0.5P CASE 506CC ISSUE A
click to zoom

NCP45525IMNTWG-H Details

  • Manufacturer Part Number:

    NCP45525IMNTWG-H

  • Brand Name:

    onsemi

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Part Package Code:

    DFN8 2x2, 0.5P

  • Package Description:

    DFN-8

  • Pin Count:

    8

  • Manufacturer Package Code:

    506CC

  • Country Of Origin:

    Thailand

  • HTS Code:

    8542.39.00.60

  • Manufacturer:

    onsemi

  • YTEOL:

    9

  • Adjustable Threshold:

    NO

  • Analog IC - Other Type:

    SPST

  • JESD-30 Code:

    S-PDSO-N8

  • JESD-609 Code:

    e3

  • Length:

    2 mm

  • Moisture Sensitivity Level:

    3

  • Number of Channels:

    1

  • Number of Functions:

    1

  • Number of Terminals:

    8

  • On-state Resistance Match-Nom:

    0.000021 Ω

  • On-state Resistance-Max (Ron):

    0.0317 Ω

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    HVSON

  • Package Equivalence Code:

    SOLCC8,.08,20

  • Package Shape:

    SQUARE

  • Package Style:

    SMALL OUTLINE, HEAT SINK/SLUG, VERY THIN PROFILE

  • Peak Reflow Temperature (Cel):

    260

  • Seated Height-Max:

    1 mm

  • Supply Current-Max (Isup):

    0.68 mA

  • Supply Voltage-Max (Vsup):

    5.5 V

  • Supply Voltage-Min (Vsup):

    3 V

  • Supply Voltage-Nom (Vsup):

    3.3 V

  • Surface Mount:

    YES

  • Switching:

    BREAK-BEFORE-MAKE

  • Temperature Grade:

    INDUSTRIAL

  • Terminal Finish:

    Matte Tin (Sn) - annealed

  • Terminal Form:

    NO LEAD

  • Terminal Pitch:

    0.5 mm

  • Terminal Position:

    DUAL

  • Time@Peak Reflow Temperature-Max (s):

    30

  • Width:

    2 mm

NCP45525IMNTWG-H Frequently Asked Questions (FAQs)

  • A good PCB layout for optimal thermal performance involves placing the device near a thermal pad or a heat sink, and ensuring good thermal conductivity between the device and the PCB. A 2-layer or 4-layer PCB with a solid ground plane is recommended. Avoid placing thermal vias under the device, and keep the thermal pad clear of any obstacles.
  • To ensure proper biasing, connect the EN pin to a voltage source (e.g., VCC) through a 10kΩ resistor, and connect the FB pin to the output voltage through a resistive divider. The resistive divider should be chosen to set the desired output voltage. Additionally, ensure that the input voltage is within the recommended operating range.
  • Critical components to consider when designing a power supply with the NCP45525IMNTWG-H include the input capacitor (CIN), output capacitor (COUT), and inductor (L). Choose components with suitable voltage and current ratings, and ensure that the inductor has a low DC resistance to minimize power losses.
  • To troubleshoot issues with the device, start by checking the PCB layout and component placement for any potential issues. Verify that the input voltage is within the recommended operating range and that the output voltage is within the desired range. Check for any signs of overheating, and ensure that the device is properly biased. If issues persist, consult the datasheet and application notes for guidance.
  • Key considerations for thermal management include ensuring good airflow around the device, using a heat sink or thermal pad, and keeping the device away from other heat sources. The device's thermal pad should be connected to a solid ground plane or a heat sink to dissipate heat efficiently.
