NCS01W8-48S050 - Cincon

NCS01W8-48S050 Details

• Manufacturer Part Number:

  NCS01W8-48S050

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• Manufacturer:

  Cincon Electronics Corporation

• YTEOL:

  5

• Additional Feature:

  TERMINAL PITCH FROM CASE PIN TO +VIN PIN IS 3.21

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  CE; EN; IEC; UKCA; UL

• Efficiency (Main Output):

  88%

• Input Voltage-Max:

  72 V

• Input Voltage-Min:

  8 V

• Input Voltage-Nom:

  48 V

• JESD-30 Code:

  R-MSIP-T5

• Length:

  12.1 mm

• Line Regulation-Max:

  0.5%

• Load Regulation-Max:

  0.6%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  5

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  1 A

• Output Voltage-Max:

  5.1 V

• Output Voltage-Min:

  4.9 V

• Output Voltage-Nom:

  5 V

• Package Body Material:

  METAL

• Package Code:

  SIP

• Package Equivalence Code:

  SIP5,.13

• Package Shape:

  RECTANGULAR

• Package Style:

  IN-LINE

• Protections:

  UNDER VOLTAGE; OVER CURRENT; THERMAL

• Ripple Voltage (Main Out):

  0.0265125 Vrms

• Screening Level:

  EN/IEC/UL 62368-1

• Seated Height-Max:

  18 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Finish:

  Matte Tin (Sn)

• Terminal Form:

  THROUGH-HOLE

• Terminal Pitch:

  2.54 mm

• Terminal Position:

  SINGLE

• Total Power Output-Max:

  5 W

• Trim/Adjustable Output:

  NO

• Warm-up Time:

  0.033 s

• Width:

  8.6 mm
