NCV7450DB0R2G - onsemi

Description: 5 V ±2% / 250 mA LDO ♦ Current Limitation ♦ Output Voltage Monitoring; One High−Speed CAN Transceiver ♦ Current Limitation, Reverse Current Protected ♦ Compliant to ISO11898−2:2016 ♦ TxDC Time−out; One High−Side Driver ♦ Rdson = 300 m? @ 25°C ♦ Current Limitation ♦ Diagnostic Output ♦ Over−Current Protection ♦ Under−Load Detection; Direct Control; Window Watchdog; Two−level Thermal Shutdown Protection; AEC−Q100 Qualified and PPAP Capable; These Devices are Pb−Free, Halogen Free/BFR Free and are RoHS Complia

Download NCV7450DB0R2G Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
NCV7450DB0R2G - onsemi PCB footprint - Small Outline Packages - Small Outline Packages - NCV7450DB0R2G
click to zoom
3D Models
NCV7450DB0R2G - onsemi  - 3D model - Small Outline Packages - NCV7450DB0R2G
click to zoom

NCV7450DB0R2G Details

  • Manufacturer Part Number:

    NCV7450DB0R2G

  • Brand Name:

    onsemi

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Part Package Code:

    TSSOP-16 EP

  • Package Description:

    TSSOP-16

  • Manufacturer Package Code:

    948BV

  • Country Of Origin:

    Thailand

  • HTS Code:

    8542.39.00.01

  • Factory Lead Time:

    24 Weeks

  • Manufacturer:

    onsemi

  • YTEOL:

    7

  • Data Rate:

    5000 Mbps

  • JESD-30 Code:

    R-PDSO-G16

  • JESD-609 Code:

    e3

  • Length:

    5 mm

  • Moisture Sensitivity Level:

    2

  • Number of Functions:

    1

  • Number of Terminals:

    16

  • Number of Transceivers:

    1

  • Operating Temperature-Max:

    125 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    HTSSOP

  • Package Equivalence Code:

    TSSOP16,.25

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE, HEAT SINK/SLUG, THIN PROFILE, SHRINK PITCH

  • Peak Reflow Temperature (Cel):

    260

  • Screening Level:

    AEC-Q100

  • Seated Height-Max:

    1.1 mm

  • Supply Voltage-Nom:

    6 V

  • Surface Mount:

    YES

  • Technology:

    CMOS

  • Telecom IC Type:

    CAN FD TRANSCEIVER

  • Temperature Grade:

    AUTOMOTIVE

  • Terminal Finish:

    Matte Tin (Sn) - annealed

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    0.65 mm

  • Terminal Position:

    DUAL

  • Time@Peak Reflow Temperature-Max (s):

    30

  • Width:

    4.4 mm

NCV7450DB0R2G Frequently Asked Questions (FAQs)

  • The maximum operating temperature range for the NCV7450DB0R2G is -40°C to 150°C.
  • To ensure the stability of the output voltage, it is recommended to use a minimum output capacitance of 10uF and a maximum ESR of 1 ohm. Additionally, the output voltage can be stabilized by adding a 10nF capacitor between the VOUT and GND pins.
  • The recommended input capacitor value for the NCV7450DB0R2G is 10uF to 22uF, with a voltage rating of 25V or higher.
  • The output current capability of the NCV7450DB0R2G can be calculated using the formula: IOUT = (VIN - VOUT) / RDS(ON). Where RDS(ON) is the on-state resistance of the internal MOSFET.
  • The EN (Enable) pin is used to enable or disable the output voltage of the NCV7450DB0R2G. When the EN pin is pulled high, the output voltage is enabled. When the EN pin is pulled low, the output voltage is disabled.
