NI-10M-2500 - TAITIEN

NI-10M-2500 Details

• Manufacturer Part Number:

  NI-10M-2500

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  DIP-5

• Manufacturer:

  Taitien Electronics Co Ltd

• YTEOL:

  9

• Aging:

  0.05 PPM/YEAR

• Control Voltage-Max:

  5 V

• Frequency Adjustment-Mechanical:

  NO

• Frequency Stability:

  0.003%

• Frequency Stability-Voltage:

  0.0005 ppm

• Input Power:

  1.3 W

• Mounting Feature:

  THROUGH HOLE MOUNT

• Number of Terminals:

  5

• Offset Frequency:

  1 kHz

• Operating Frequency-Nom:

  10 MHz

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -30 °C

• Oscillator Type:

  SINE

• Output Impedance:

  50 Ω

• Output Level:

  1.589 V

• Oven Supply Voltage:

  5V

• Package Equivalence Code:

  DIP5,.7,350

• Phase Noise:

  -148 dBc/Hz

• Physical Dimension:

  36.32mm x 27.18mm x 12.7mm

• Screening Level:

  MIL-STD-202

• Supply Voltage-Max:

  5.25 V

• Supply Voltage-Min:

  4.75 V

• Supply Voltage-Nom:

  5 V

• Surface Mount:

  NO

• Terminal Finish:

  TIN SILVER COPPER OVER NICKEL

• Warm-up Power:

  4 W

• Warm-up Time-Max:

  10 Minute
