NJG1161PCD - Nisshinbo

NJG1161PCD Details

• Manufacturer Part Number:

  NJG1161PCD

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  PACKAGE-10

• HTS Code:

  8542.39.00.01

• Manufacturer:

  Nisshinbo Micro Devices

• YTEOL:

  8

• JESD-30 Code:

  S-XBCC-B10

• Length:

  2.5 mm

• Number of Functions:

  1

• Number of Terminals:

  10

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  UNSPECIFIED

• Package Code:

  BCC

• Package Equivalence Code:

  LCC10,.09SQ,20

• Package Shape:

  SQUARE

• Package Style:

  CHIP CARRIER

• Seated Height-Max:

  0.63 mm

• Supply Current-Max:

  6.4 mA

• Supply Voltage-Nom:

  2.8 V

• Surface Mount:

  YES

• Telecom IC Type:

  RF AND BASEBAND CIRCUIT

• Terminal Form:

  BUTT

• Terminal Pitch:

  0.5 mm

• Terminal Position:

  BOTTOM

• Width:

  2.5 mm
