NJL3281DG - onsemi

NJL3281DG Details

• Manufacturer Part Number:

  NJL3281DG

• Brand Name:

  onsemi

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Part Package Code:

  TO-264, 5-Lead

• Package Description:

  TO-264, 5 PIN

• Pin Count:

  5

• Manufacturer Package Code:

  340AA

• Country Of Origin:

  South Korea

• ECCN Code:

  EAR99

• Factory Lead Time:

  8 Weeks

• Manufacturer:

  onsemi

• YTEOL:

  4

• Additional Feature:

  HIGH RELIABILITY

• Collector Current-Max (IC):

  15 A

• Collector-Emitter Voltage-Max:

  260 V

• Configuration:

  SINGLE WITH BUILT-IN DIODE

• DC Current Gain-Min (hFE):

  45

• JESD-30 Code:

  R-PSFM-T5

• JESD-609 Code:

  e3

• Number of Elements:

  1

• Number of Terminals:

  5

• Operating Temperature-Max:

  150 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  FLANGE MOUNT

• Polarity/Channel Type:

  NPN

• Power Dissipation-Max (Abs):

  200 W

• Qualification Status:

  Not Qualified

• Surface Mount:

  NO

• Terminal Finish:

  MATTE TIN

• Terminal Form:

  THROUGH-HOLE

• Terminal Position:

  SINGLE

• Transistor Application:

  AMPLIFIER

• Transistor Element Material:

  SILICON

• Transition Frequency-Nom (fT):

  30 MHz
