NJM2119M - Nisshinbo

Description: Op Amp, 1MHz, 5 → 28 V, 8-Pin DMP

Download NJM2119M Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
NJM2119M - Nisshinbo PCB footprint - Small Outline Packages - Small Outline Packages - DMP8
click to zoom
3D Models
NJM2119M - Nisshinbo  - 3D model - Small Outline Packages - DMP8
click to zoom

NJM2119M Details

  • Manufacturer Part Number:

    NJM2119M

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.33.00.01

  • Factory Lead Time:

    12 Weeks

  • Manufacturer:

    Nisshinbo Micro Devices

  • YTEOL:

    10

  • Amplifier Type:

    OPERATIONAL AMPLIFIER

  • Architecture:

    VOLTAGE-FEEDBACK

  • Average Bias Current-Max (IIB):

    0.05 µA

  • Bias Current-Max (IIB) @25C:

    0.05 µA

  • Common-mode Reject Ratio-Min:

    85 dB

  • Common-mode Reject Ratio-Nom:

    100 dB

  • Frequency Compensation:

    YES

  • Input Offset Voltage-Max:

    450 µV

  • JESD-30 Code:

    S-PDSO-G8

  • JESD-609 Code:

    e6

  • Length:

    5 mm

  • Low-Bias:

    NO

  • Low-Offset:

    YES

  • Micropower:

    YES

  • Number of Functions:

    2

  • Number of Terminals:

    8

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -30 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    SOP

  • Package Equivalence Code:

    SOP8,.25

  • Package Shape:

    SQUARE

  • Package Style:

    SMALL OUTLINE

  • Power:

    NO

  • Programmable Power:

    NO

  • Qualification Status:

    Not Qualified

  • Seated Height-Max:

    2 mm

  • Slew Rate-Nom:

    0.3 V/us

  • Supply Current-Max:

    1.5 mA

  • Supply Voltage Limit-Max:

    36 V

  • Supply Voltage-Nom (Vsup):

    5 V

  • Surface Mount:

    YES

  • Technology:

    BIPOLAR

  • Temperature Grade:

    OTHER

  • Terminal Finish:

    TIN BISMUTH

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    1.27 mm

  • Terminal Position:

    DUAL

  • Unity Gain BW-Nom:

    1000

  • Voltage Gain-Min:

    31622.8

  • Wideband:

    NO

  • Width:

    5 mm

NJM2119M Frequently Asked Questions (FAQs)

  • The recommended operating voltage range for NJM2119M is 2.7V to 5.5V.
  • To ensure stability in the output voltage, it is recommended to use a minimum output capacitance of 10uF and a maximum ESR of 1 ohm.
  • The maximum output current of NJM2119M is 1.5A.
  • To protect NJM2119M from overheating, ensure that the device is mounted on a heat sink or a PCB with a thermal pad, and that the ambient temperature is within the recommended range of -40°C to 85°C.
  • While NJM2119M can operate up to 85°C, it is recommended to derate the output current and voltage to ensure reliability in high-temperature environments.
