NJM2370U1-10 - Nisshinbo

NJM2370U1-10 Details

• Manufacturer Part Number:

  NJM2370U1-10

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  SOT-89, 5 PIN

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  Nisshinbo Micro Devices

• YTEOL:

  6.4

• Dropout Voltage1-Max:

  0.3 V

• Dropout Voltage1-Nom:

  0.1 V

• Input Voltage-Max:

  16.3 V

• Input Voltage-Min:

  10.7 V

• JESD-30 Code:

  R-PDSO-F5

• JESD-609 Code:

  e6

• Length:

  4.5 mm

• Load Regulation-Max(%):

  0.18%

• Moisture Sensitivity Level:

  1

• Number of Functions:

  1

• Number of Terminals:

  5

• Output Current1-Max:

  0.18 A

• Output Voltage1-Max:

  10.3 V

• Output Voltage1-Min:

  9.7 V

• Output Voltage1-Nom:

  10 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  SOF

• Package Equivalence Code:

  TO-243

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Peak Reflow Temperature (Cel):

  260

• Qualification Status:

  Not Qualified

• Regulator Type:

  FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR

• Seated Height-Max:

  1.8 mm

• Surface Mount:

  YES

• Technology:

  BIPOLAR

• Terminal Finish:

  Tin/Bismuth (Sn/Bi)

• Terminal Form:

  FLAT

• Terminal Pitch:

  1.5 mm

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  10

• Voltage Tolerance-Max:

  3%

• Width:

  2.5 mm
