A good PCB layout for NJM4580E-TE1 involves keeping the input and output traces short and separate, using a solid ground plane, and placing decoupling capacitors close to the device. A 4-layer PCB with a dedicated power plane and a dedicated ground plane is recommended.
To ensure stability, make sure to follow the recommended compensation capacitor values, keep the gain above 5, and avoid capacitive loads. Also, use a low-ESR capacitor for decoupling and keep the power supply noise low.
The maximum power dissipation of NJM4580E-TE1 is 1.4W. However, this value can be derated based on the ambient temperature and the thermal resistance of the PCB.
Yes, NJM4580E-TE1 can be used as a unity gain buffer. However, it's recommended to add a compensation capacitor (e.g., 22pF) between the output and the inverting input to ensure stability.
To protect NJM4580E-TE1 from ESD damage, use ESD protection devices such as TVS diodes or ESD arrays at the input and output pins. Also, follow proper handling and storage procedures to prevent ESD damage.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
NJM4580E-TE1 Overview
Use the download button to access the NJM4580E-TE1 schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like NJM45,
or try a keyword search, such as Operational Amplifiers
