NJU7670M - Nisshinbo

NJU7670M Details

• Manufacturer Part Number:

  NJU7670M

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  Nisshinbo Micro Devices

• YTEOL:

  8

• Additional Feature:

  ALSO CONFIGURED AS DOUBLER AND VREG OUTPUT VOLTAGE IS FORM -2.6V TO -18V

• Analog IC - Other Type:

  SWITCHED CAPACITOR REGULATOR

• Input Voltage-Max:

  -6 V

• Input Voltage-Min:

  -2.6 V

• Input Voltage-Nom:

  -5 V

• JESD-30 Code:

  R-PDSO-G14

• JESD-609 Code:

  e6

• Number of Functions:

  1

• Number of Terminals:

  14

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -20 °C

• Output Current-Max:

  0.02 A

• Output Voltage-Max:

  -18 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Qualification Status:

  Not Qualified

• Supply Current-Max (Isup):

  0.12 mA

• Surface Mount:

  YES

• Switcher Configuration:

  TRIPLER

• Switching Frequency-Max:

  2.5 kHz

• Technology:

  CMOS

• Temperature Grade:

  OTHER

• Terminal Form:

  GULL WING

• Terminal Position:

  DUAL
