NJU77552G-TE2 - Nisshinbo

Description: FEATURES (V+ = 5V, Typical value) ● High Efficiency: - GBW 1.7MHz - Supply Current 50μA/ch ● Rail-to-Rail Input and Output ● Supply Voltage 1.8V to 5.5V ● Integrated EMI filter EMIRR = 75dB @f = 900MHz ● Input Tolerant ● Unity-Gain stable ● Input Offset Voltage 5mV max. ● Slew Rate 0.8V/μs ● Operating Temperature -55°C to 125°C ● Package NJU77550 / NJU77551 SOT-23-5, SC-88A NJU77552 SOP8, MSOP8 (TVSP8)* * meet JEDEC MO-187-DA / thin type DFN8-U1 (ESON8-U1) NJU77554
