NL3V8T240MU2TAG - onsemi

NL3V8T240MU2TAG Details

• Manufacturer Part Number:

  NL3V8T240MU2TAG

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  UDFN-20

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  onsemi

• YTEOL:

  8

• Delay-Max:

  14.7 ns

• Interface IC Type:

  VOLTAGE LEVEL TRANSLATOR

• JESD-30 Code:

  R-PDSO-N20

• Length:

  4 mm

• Moisture Sensitivity Level:

  1

• Number of Bits:

  8

• Number of Functions:

  1

• Number of Terminals:

  20

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Output Characteristics:

  3-STATE

• Output Polarity:

  TRUE

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  VSON

• Package Equivalence Code:

  SOLCC20,.08,16

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE, VERY THIN PROFILE

• Seated Height-Max:

  0.55 mm

• Supply Voltage-Max:

  3.6 V

• Supply Voltage-Min:

  0.9 V

• Supply Voltage-Nom:

  1.1 V

• Supply Voltage1-Max:

  3.6 V

• Supply Voltage1-Min:

  0.9 V

• Supply Voltage1-Nom:

  1.1 V

• Surface Mount:

  YES

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  0.4 mm

• Terminal Position:

  DUAL

• Width:

  2 mm
