NLA9555DTR2G - onsemi

Description: VDD Operating Range: 1.65 V to 5.5 V; SDA Sink Capability: 30 mA; 5.5 V Tolerant I/Os; Polarity Inversion Register; Active LOW Interrupt Output; Low Standby Current; Noise Filter on SCL/SDA Inputs; No Glitch on Powerup; Internal Power-On Reset; 64 Programmable Slave Addresses using Three Address Pins; 16 I/O Pins which Default to 16 Inputs

Download NLA9555DTR2G Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
NLA9555DTR2G - onsemi PCB footprint - Small Outline Packages - Small Outline Packages - TSSOP24 DT CASE 948H ISSUE B
click to zoom

NLA9555DTR2G Details

  • Manufacturer Part Number:

    NLA9555DTR2G

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Date Of Intro:

    2019-01-16

  • Manufacturer:

    onsemi

  • uPs/uCs/Peripheral ICs Type:

    PARALLEL IO PORT, GENERAL PURPOSE

Trust Checks

This model has been built in collaboration with the manufacturer.
Manufacturer Collaborated
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

NLA9555DTR2G Overview

Use the download button to access the NLA9555DTR2G schematic symbol and PCB footprint.
To find more CAD model downloads similar to this part, try a partial part number search, like NLA95, or try a keyword search, such as Parallel IO Ports
