NOIP1FN016KA-GTI - onsemi

NOIP1FN016KA-GTI Details

• Manufacturer Part Number:

  NOIP1FN016KA-GTI

• Brand Name:

  onsemi

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Part Package Code:

  CPGA-355

• Manufacturer Package Code:

  107DJ

• Country Of Origin:

  Thailand

• Factory Lead Time:

  20 Weeks

• Date Of Intro:

  2018-05-09

• Manufacturer:

  onsemi

• YTEOL:

  8.1

• Additional Feature:

  GLOBAL SHUTTER; IT ALSO OPERATES AT 3.3 V NOMINAL SUPPLY VOLTAGE

• Array Type:

  FRAME

• Body Breadth:

  36.1 mm

• Body Height:

  3.5 mm

• Body Length or Diameter:

  43.1 mm

• Dynamic Range:

  59 dB

• Frame Rate:

  120 fps

• Horizontal Pixel:

  4096

• Master Clock:

  360 MHz

• Mounting Feature:

  THROUGH HOLE MOUNT

• Operating Current-Max:

  540 mA

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Output Interface Type:

  4-WIRE INTERFACE

• Output Type:

  DIGITAL OUTPUT

• Package Shape/Style:

  RECTANGULAR

• Pixel Size:

  4.5X4.5 µm

• Sensitivity (V/lx.s):

  5.8 V/lx.s

• Sensors/Transducers Type:

  IMAGE SENSOR,CMOS

• Spectral Response (nm):

  300-1100

• Supply Voltage-Max:

  1.9 V

• Supply Voltage-Min:

  1.7 V

• Surface Mount:

  NO

• Termination Type:

  SOLDER

• Vertical Pixel:

  4096
