NP89N055NUK-S18-AY - Renesas Electronics

NP89N055NUK-S18-AY Details

• Manufacturer Part Number:

  NP89N055NUK-S18-AY

• Brand Name:

  Renesas

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  MP-25SK

• Package Description:

  TO-262, 3 PIN

• Pin Count:

  3

• Manufacturer Package Code:

  PRSS0004AM

• ECCN Code:

  EAR99

• Manufacturer:

  Renesas Electronics Corporation

• YTEOL:

  0

• Case Connection:

  DRAIN

• Configuration:

  SINGLE

• DS Breakdown Voltage-Min:

  55 V

• Drain Current-Max (ID):

  90 A

• Drain-source On Resistance-Max:

  0.0044 Ω

• FET Technology:

  METAL-OXIDE SEMICONDUCTOR

• Feedback Cap-Max (Crss):

  270 pF

• JEDEC-95 Code:

  TO-262AA

• JESD-30 Code:

  R-PSIP-T3

• Number of Elements:

  1

• Number of Terminals:

  3

• Operating Mode:

  ENHANCEMENT MODE

• Operating Temperature-Max:

  175 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  IN-LINE

• Packing Method:

  TUBE

• Polarity/Channel Type:

  N-CHANNEL

• Power Dissipation Ambient-Max:

  1.8 W

• Power Dissipation-Max (Abs):

  147 W

• Pulsed Drain Current-Max (IDM):

  360 A

• Reference Standard:

  AEC-Q101

• Surface Mount:

  NO

• Terminal Form:

  THROUGH-HOLE

• Terminal Position:

  SINGLE

• Transistor Application:

  SWITCHING

• Transistor Element Material:

  SILICON

• Turn-off Time-Max (toff):

  130 ns

• Turn-on Time-Max (ton):

  60 ns
