NRJ6HM-1 - Neutrik

NRJ6HM-1 Details

• Manufacturer Part Number:

  NRJ6HM-1

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.10

• Manufacturer:

  Neutrik USA Inc

• YTEOL:

  7

• Audio Type:

  STEREO

• Body Breadth:

  0.5 inch

• Body Depth:

  1.299 inch

• Body Length:

  0.62 inch

• Body/Shell Style:

  JACK

• Configuration:

  2X3 HORIZONTAL

• Connector Type:

  6.3MM AUDIO

• Contact Gender:

  FEMALE

• Contact Resistance:

  25 mΩ

• Contact Style:

  RND PIN-SKT

• Dielectric Withstanding Voltage:

  1000VDC V

• Durability:

  10000 Cycles

• Insertion Force-Max:

  30 N

• Insulation Resistance:

  1000000000 Ω

• Insulator Material:

  GLASS FILLED POLYAMIDE66

• Mounting Option 1:

  LOCKING

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD AND PANEL

• Number of Poles:

  3

• Number of Ports:

  1

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -25 °C

• Option:

  GENERAL PURPOSE

• Plating Thickness:

  79u inch

• Rated Current (Signal):

  3 A

• Reference Standard:

  EIA, IEC

• Terminal Length:

  0.124 inch

• Termination Type:

  SOLDER
