NTE2349 - NTE ELECTRONICS

NTE2349 Details

• Manufacturer Part Number:

  NTE2349

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• ECCN Code:

  EAR99

• HTS Code:

  8541.29.00.95

• Manufacturer:

  NTE Electronics Inc

• YTEOL:

  0

• Case Connection:

  COLLECTOR

• Collector Current-Max (IC):

  50 A

• Collector-Emitter Voltage-Max:

  120 V

• Configuration:

  DARLINGTON WITH BUILT-IN DIODE AND RESISTOR

• DC Current Gain-Min (hFE):

  400

• JEDEC-95 Code:

  TO-3

• JESD-30 Code:

  O-MBFM-P2

• Number of Elements:

  1

• Number of Terminals:

  2

• Package Body Material:

  METAL

• Package Shape:

  ROUND

• Package Style:

  FLANGE MOUNT

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Polarity/Channel Type:

  NPN

• Power Dissipation Ambient-Max:

  300 W

• Power Dissipation-Max (Abs):

  300 W

• Qualification Status:

  Not Qualified

• Surface Mount:

  NO

• Terminal Form:

  PIN/PEG

• Terminal Position:

  BOTTOM

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED

• Transistor Element Material:

  SILICON
