NTTFD4D0N04HLTWG - onsemi

NTTFD4D0N04HLTWG Details

• Manufacturer Part Number:

  NTTFD4D0N04HLTWG

• Brand Name:

  onsemi

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Part Package Code:

  WQFN-12

• Package Description:

  WQFN-12

• Manufacturer Package Code:

  510CJ

• Country Of Origin:

  Philippines

• ECCN Code:

  EAR99

• HTS Code:

  8541.29.00.95

• Factory Lead Time:

  14 Weeks

• Date Of Intro:

  2020-02-19

• Manufacturer:

  onsemi

• YTEOL:

  5.6

• Avalanche Energy Rating (Eas):

  67 mJ

• Configuration:

  2 BANKS, SERIES CONNECTED, CENTER TAP, 2 ELEMENTS WITH BUILT-IN DIODE

• DS Breakdown Voltage-Min:

  40 V

• Drain Current-Max (ID):

  60 A

• Drain-source On Resistance-Max:

  0.007 Ω

• FET Technology:

  METAL-OXIDE SEMICONDUCTOR

• JESD-30 Code:

  S-PQCC-N12

• JESD-609 Code:

  e3

• Moisture Sensitivity Level:

  1

• Number of Elements:

  2

• Number of Terminals:

  12

• Operating Mode:

  ENHANCEMENT MODE

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  SQUARE

• Package Style:

  CHIP CARRIER

• Peak Reflow Temperature (Cel):

  260

• Polarity/Channel Type:

  N-CHANNEL AND P-CHANNEL

• Power Dissipation Ambient-Max:

  1.7 W

• Power Dissipation-Max (Abs):

  26 W

• Pulsed Drain Current-Max (IDM):

  349 A

• Surface Mount:

  YES

• Terminal Finish:

  Matte Tin (Sn) - annealed

• Terminal Form:

  NO LEAD

• Terminal Position:

  QUAD

• Time@Peak Reflow Temperature-Max (s):

  30

• Transistor Application:

  SWITCHING

• Transistor Element Material:

  SILICON
