NVMFD5877NLT1G - onsemi

NVMFD5877NLT1G Details

• Manufacturer Part Number:

  NVMFD5877NLT1G

• Brand Name:

  onsemi

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  DFN8 5x6, 1.27P Dual Flag (SO8FL-Dual)

• Package Description:

  SO-8FL, DFN-8

• Pin Count:

  8

• Manufacturer Package Code:

  506BT

• ECCN Code:

  EAR99

• Manufacturer:

  onsemi

• YTEOL:

  0

• Avalanche Energy Rating (Eas):

  10.5 mJ

• Case Connection:

  DRAIN

• Configuration:

  SEPARATE, 2 ELEMENTS WITH BUILT-IN DIODE

• DS Breakdown Voltage-Min:

  60 V

• Drain Current-Max (ID):

  6 A

• Drain-source On Resistance-Max:

  0.06 Ω

• FET Technology:

  METAL-OXIDE SEMICONDUCTOR

• Feedback Cap-Max (Crss):

  36 pF

• JESD-30 Code:

  R-PDSO-F8

• JESD-609 Code:

  e3

• Moisture Sensitivity Level:

  1

• Number of Elements:

  2

• Number of Terminals:

  8

• Operating Mode:

  ENHANCEMENT MODE

• Operating Temperature-Max:

  175 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Peak Reflow Temperature (Cel):

  260

• Polarity/Channel Type:

  N-CHANNEL

• Power Dissipation-Max (Abs):

  23 W

• Pulsed Drain Current-Max (IDM):

  74 A

• Qualification Status:

  Not Qualified

• Reference Standard:

  AEC-Q101

• Surface Mount:

  YES

• Terminal Finish:

  Matte Tin (Sn) - annealed

• Terminal Form:

  FLAT

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  30

• Transistor Element Material:

  SILICON
