NXT4556AURZ - Nexperia

NXT4556AURZ Details

• Manufacturer Part Number:

  NXT4556AURZ

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  WLCSP-9

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  Nexperia

• YTEOL:

  8

• Delay-Max:

  25 ns

• Interface IC Type:

  VOLTAGE LEVEL TRANSLATOR

• JESD-30 Code:

  S-XBCS-B9

• Length:

  0.92 mm

• Number of Bits:

  1

• Number of Functions:

  1

• Number of Terminals:

  9

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Output Latch or Register:

  NONE

• Output Polarity:

  TRUE

• Package Body Material:

  UNSPECIFIED

• Package Code:

  CSP

• Package Equivalence Code:

  BGA9,3X3,12

• Package Shape:

  SQUARE

• Package Style:

  CHIP SCALE

• Seated Height-Max:

  0.415 mm

• Supply Current-Max:

  0.3 mA

• Supply Voltage-Max:

  1.98 V

• Supply Voltage-Min:

  1.08 V

• Supply Voltage-Nom:

  1.2 V

• Supply Voltage1-Max:

  3.3 V

• Supply Voltage1-Min:

  1.62 V

• Supply Voltage1-Nom:

  1.8 V

• Surface Mount:

  YES

• Terminal Form:

  BALL

• Terminal Pitch:

  0.3 mm

• Terminal Position:

  BOTTOM

• Width:

  0.92 mm
