NXU0104PWJ - Nexperia

NXU0104PWJ Details

• Manufacturer Part Number:

  NXU0104PWJ

• Part Life Cycle Code:

  Active

• Package Description:

  TSSOP-14

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  Nexperia

• YTEOL:

  8

• Delay-Max:

  42.1 ns

• Input Characteristics:

  SCHMITT TRIGGER

• Interface IC Type:

  VOLTAGE LEVEL TRANSLATOR

• JESD-30 Code:

  R-PDSO-G14

• Length:

  5 mm

• Number of Bits:

  4

• Number of Functions:

  1

• Number of Terminals:

  14

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Output Characteristics:

  3-STATE

• Output Latch or Register:

  NONE

• Output Polarity:

  TRUE

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  TSSOP

• Package Equivalence Code:

  TSSOP14,.25

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE, THIN PROFILE, SHRINK PITCH

• Seated Height-Max:

  1.2 mm

• Supply Current-Max:

  0.005 mA

• Supply Voltage-Max:

  5.5 V

• Supply Voltage-Min:

  0.9 V

• Supply Voltage-Nom:

  1.1 V

• Supply Voltage1-Max:

  5.5 V

• Supply Voltage1-Min:

  0.9 V

• Supply Voltage1-Nom:

  1.1 V

• Surface Mount:

  YES

• Terminal Form:

  GULL WING

• Terminal Pitch:

  0.65 mm

• Terminal Position:

  DUAL

• Width:

  4.4 mm
