O-CS8-0PS17EWU-R-100.000MHZ - ABRACON

O-CS8-0PS17EWU-R-100.000MHZ Details

• Manufacturer Part Number:

  O-CS8-0PS17EWU-R-100.000MHZ

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  SMD, 8 PIN

• Factory Lead Time:

  36 Weeks

• Manufacturer:

  Abracon Corporation

• YTEOL:

  9

• Aging:

  0.5 PPM/FIRST YEAR

• Control Voltage-Max:

  4.5 V

• Frequency Adjustment-Mechanical:

  NO

• Frequency Stability:

  0.1%

• Frequency Stability-Voltage:

  0.002 ppm

• Input Power:

  1.2 W

• Mounting Feature:

  SURFACE MOUNT

• Number of Terminals:

  8

• Offset Frequency:

  1 kHz

• Operating Frequency-Nom:

  100 MHz

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -20 °C

• Oscillator Type:

  SINE

• Output Impedance:

  50 Ω

• Output Level:

  3.557 V

• Oven Supply Voltage:

  5V

• Package Equivalence Code:

  DILCC8,.55

• Phase Noise:

  -162 dBc/Hz

• Physical Dimension:

  21.08mm x 14.0mm x 7.49mm

• Screening Level:

  MIL-STD-883; MIL-STD-202

• Supply Current-Max:

  240 mA

• Supply Voltage-Max:

  5.25 V

• Supply Voltage-Min:

  4.75 V

• Supply Voltage-Nom:

  5 V

• Surface Mount:

  YES

• Warm-up Power:

  3.5 W

• Warm-up Time-Max:

  5 Minute
