OD100LP-61012SV-010.0M Frequently Asked Questions (FAQs)

• What is the recommended PCB layout for optimal performance?
  Connor-Winfield recommends a 4-layer PCB with a dedicated ground plane and a solid copper pour on the top and bottom layers to minimize noise and ensure optimal signal integrity.
• How do I ensure the oscillator is properly terminated?
  The OD-61012SV-010.0M requires a 50Ω load termination. Ensure the output is connected to a 50Ω load, such as a resistor or a transmission line, to prevent signal reflections and ensure proper signal transmission.
• What is the maximum operating temperature range for this oscillator?
  The OD-61012SV-010.0M is specified to operate from -40°C to 85°C. However, it's essential to note that the frequency stability and accuracy may degrade at extreme temperatures. Consult the datasheet for specific temperature-related performance characteristics.
• Can I use this oscillator in a high-vibration environment?
  The OD-61012SV-010.0M is designed to meet the requirements of MIL-STD-202, Method 204, Condition D, which includes vibration testing. However, it's crucial to ensure the PCB is properly mounted and secured to prevent mechanical stress on the oscillator.
• What is the typical start-up time for this oscillator?
  The start-up time for the OD-61012SV-010.0M is typically around 10ms. However, this may vary depending on the specific application, power supply, and environmental conditions.
